Transformers

Transformers represent the successive operations that can be applied to a media to create a variation.

Available transformers

The bundle ships with multiple transformers that aim at allowing for the most common operations on media files. If you have specific needs, you can also implement your own pre-processor.

Crop

This transformer crops a part of the image based on coordinates. It is useful if you want to extract a specific part of the image.

crop:
    start_x: 10%
    start_y: 20%
    width: 50%
    height: 300

If the start coordinates are outside the image, the image will not be modified. If the start coordinates are not defined, the image will be cropped around the center of the image.

If the width or height of the crop area is larger than the image, only the part of the crop area that fits in the image will be used. If the width or height of the crop area is smaller than the image, the image will be cropped to fit the crop area.

Options:

  • start_x: the X coordinate of the top-left corner of the crop area. The value can either be an absolute pixel value (e.g. 300), or a percentage of the image width (e.g. 50%).
  • start_y: the Y coordinate of the top-left corner of the crop area. The value can either be an absolute pixel value (e.g. 300), or a percentage of the image height (e.g. 50%).
  • width: the width of the crop area. The value can either be an absolute pixel value (e.g. 300), or a percentage of the image width (e.g. 50%).
  • height: the height of the crop area. The value can either be an absolute pixel value (e.g. 300), or a percentage of the image height (e.g. 50%).

Tip

This transformer does not resize the image, it only crops it. If you want to resize the image to fit the crop area, you can use the thumbnail transformer instead.

Expand

This transformer expands the image to a specific width and height, by adding a background color to the image. It is useful if you want to add a background color to an image that is smaller than the target size, or if you want to create a specific aspect ratio for the image without cropping or distorteding it.

expand:
    width: 600
    height: 400
    background_color: red
    position_x: 100
    position_y: end

Options:

  • width: the width of the resulting image. The value can either be an absolute pixel value (e.g. 600), or a percentage of the image width (e.g. 200% to double the image width).
  • height: the height of the resulting image. The value can either be an absolute pixel value (e.g. 600), or a percentage of the image height (e.g. 200% to double the image height).
  • background_color: the background color to use for the expansion. The value can be a color name (e.g. red), a hex color (e.g. #ff0000) or an RGB color (e.g. rgb(255,0,0)). If not set, the background color will be transparent for PNG images, and white for JPEG images.
  • position_x: the X position of the image in the expanded area. The value can either be an absolute pixel value (e.g. 300), a percentage of the image width (e.g. 50%), or one of the following: start, center, end. If not set, the image will be centered in the expanded area.
  • position_y: the Y position of the image in the expanded area. The value can either be an absolute pixel value (e.g. 300), a percentage of the image height (e.g. 50%), or one of the following: start, center, end. If not set, the image will be centered in the expanded area.

If the width or height is smaller than the original image, the image will be left unchanged.

Heighten

This transformer resizes the image to a specific height, keeping the aspect ratio.

heighten:
    height: 600

Options:

  • height: the height of the image. The value can either be an absolute pixel value (e.g. 600), or a percentage of the image height (e.g. 200% to double the image height).
  • allow_downscale: whether to allow downscaling the image (default: true)
  • allow_upscale: whether to allow upscaling the image (default: true)

Resize

This transformer resizes the image to a specific width and height. There are several resize modes:

  • exact: in this mode, the image is resized to the exact dimensions specified. The aspect ratio is not preserved.
  • inside: in this mode, the image is resized to fit within the dimensions specified. The aspect ratio is preserved.
  • outside: in this mode, the image is resized to cover the dimensions specified. The aspect ratio is preserved.

For example, imagine you have an image that is 900x600 pixels.

  • resizing in exact mode to 300x300 will result in a 300x300 image - the aspect ratio is not preserved
  • resizing in inside mode to 300x300 will result in a 300x200 image - the aspect ratio is preserved
  • resizing in outside mode to 300x300 will result in a 450x300 image - the aspect ratio is preserved

Options:

  • height: the height of the image
  • width: the width of the image
  • mode: the resize mode (exact, inside or outside) - default: exact
  • allow_downscale: whether to allow downscaling the image (default: true)
  • allow_upscale: whether to allow upscaling the image (default: true)

Thumbnail

This transformer resizes the image to a specific width and height and crops it to fit the dimensions exactly. The aspect ratio of the container is not preserved but the aspect ratio of the image content is - cropping will be applied to the image content so it does not look distorted.

If the image is smaller than the specified dimensions, it will be upscaled to fit the dimensions only if the allow_upscale option is set to true. Else, the image will not be modified.

thumbnail:
    height: 200
    width: 200

Options:

  • height: the height of the resulting image
  • width: the width of the resulting image
  • allow_upscale: whether to allow upscaling the image (default: true)
  • crop_position: the position of the crop area. The value can be one of the following: start, center, end, or a percentage position from the top left corner.

For example, imagine you have an image that is 900x600 pixels. Applying the thumbnail transformer with the dimensions 300x300 will result in a 300x300 image. The image will be cropped to fit the 1:1 aspect ratio, then resized to 300x300 pixels.

By default, the crop area will be centered on the image. If you want to crop the image from the top-left corner, you can set the crop_position option to start. If you want to crop the image from the bottom-right corner, you can set the crop_position option to end.

Whith the example above (a 900x600 image) and a 300x300 thumbnail, the crop area will be defined as follows:

  • if you set the crop_position option to 25% for a 300x300 thumbnail, the resulting image will be cropped from `150x0 to 450x300.
  • if you set the crop_position option to 50%, the resulting image will be cropped from 300x0 to 600x300
  • if you set the crop_position option to 75%, the resulting image will be cropped from 450x0 to 750x300
  • if you set the crop_position option to 100%, the resulting image will be cropped from 600x0 to 900x300.

Widen

This transformer resizes the image to a specific width, keeping the aspect ratio.

widen:
    width: 600

Options:

  • width: the width of the image. The value can either be an absolute pixel value (e.g. 600), or a percentage of the image width (e.g. 200% to double the image width).
  • allow_downscale: whether to allow downscaling the image (default: true)
  • allow_upscale: whether to allow upscaling the image (default: true)

Transformers are applied sequentially

Transformers are applied in the order they are defined in the configuration file. Each transformer does not translate to an immediate physical operation on the image - instead, a transformation is computed, that is a set of operations (cropping, resizing) that will be physically applied to the image if required.

For example, if the transformers defined for a given variation do not produce any change to the image, the image will not be modified, and it will be passed through as-is to the post-processors.

When a media file is converted, the converter will apply the transformers in the order they are defined in the configuration file. With the following example:

my_variation:
    transformers:
        resize:
            width: 200
            height: 150
            mode: inside
        heighten:
            height: 600

The converter will first apply the resize transformer, then the heighten transformer, which means that you should get an image 600px tall. The order of the transformers is important: if you swap the order of the transformers in the configuration file, the output will be different (most likely an image contained in a 200x150px rectangle).

If you need to apply the same type of transformation multiple times for a given variation, you can define multiple transformers of the same type. For example, if you want to resize an image to 200x150px, then heighten it to 600px, then resizing it again to 300x200px, you can do it like this:

my_variation:
    transformers:
        - type: resize
          width: 200
          height: 150
        - type: heighten
          height: 600
        - type: resize
          width: 300
          height: 200

Example transformer configurations

This section provides some example configurations for the transformers. These examples are illustrated using the following image:

../images/example.png
Transformers sequence Original image Generated image
transformers:
    crop:
        width: 70
        height: 40
 image image
transformers:
    crop:
        width: 50
        height: 50
        start_x: 50%
        start_y: 10%
 image image
transformers:
    expand:
        width: 150
        height: 200
        background_color: '#aaffaa'
 image image
transformers:
    crop:
        width: 60
        height: 60
    expand:
        width: 150
        height: 200
        background_color: '#ffccff'
 image image
transformers:
    crop:
        width: 60
        height: 60
    expand:
        width: 200
        height: 150
        background_color: '#ffccff'
        position_x: end
        position_y: end
 image image
transformers:
    heighten:
        height: 300
 image image
transformers:
    resize:
        width: 90
        height: 150
        mode: exact
 image image
transformers:
    resize:
        width: 90
        height: 150
        mode: inside
 image image
transformers:
    resize:
        width: 90
        height: 150
        mode: outside
 image image
transformers:
    thumbnail:
        width: 40
        height: 120
 image image
transformers:
    thumbnail:
        width: 120
        height: 40
 image image
transformers:
    thumbnail:
        width: 40
        height: 120
        crop_position: start
 image image
transformers:
    thumbnail:
        width: 120
        height: 40
        crop_position: end
 image image
transformers:
    widen:
        width: 300%
 image image
transformers:
    -
        type: crop
        width: 60
        height: 60
    -
        type: expand
        width: 80
        height: 80
        background_color: '#ffcccc'
        position_x: end
        position_y: end
    -
        type: heighten
        height: 100
    -
        type: expand
        width: 120
        height: 120
        background_color: '#ccffcc'
        position_x: start
        position_y: end
    -
        type: widen
        width: 140
    -
        type: expand
        width: 160
        height: 160
        background_color: '#ccccff'
        position_x: start
        position_y: start
    -
        type: resize
        width: 180
        height: 180
        mode: exact
    -
        type: expand
        width: 200
        height: 200
        background_color: '#ffff44'
    -
        type: thumbnail
        width: 100
        height: 100
 image image
